描述
CMB系列超级移动式沥青搅拌站具有灵活性和超强机动性,很容易在工作地点之间转移;不是一个月,也不是一天,只需要几个小时就可以重新组装并重新开始生产;折叠支架和巧妙的工程简化了对地基的需求,节省了大量的停机时间和劳动力。
亮点:
01
独特的模块设计
所有模块集成在一个或两个移动单元中,移动方便,装拆复杂度低,生产效率高
02
最小热量损失
干燥筒的提升叶片和不锈钢保温层不断优化,最大限度地减少热量损失
03
轻松控制
操作模式可在自动和手动之间切换,操作员可随时切换到手动操作
04
减少排放
采用细水雾、水膜、旋风除尘过滤技术,对含尘废气有较好的截留效果
05
独特的批处理
冷料机设有防护网、缺料报警装置、自动振壁器、皮带秤(选配),并可自动控制冷骨料配比。
06
增强性能
全封闭式拖链输送机不仅可以避免热量损失,最大程度减少污染,还可以对沥青混合料进行二次搅拌,使其更加均匀
参数
型号 | CMB40 | CMB60 | CMB80 | CMB100 | CMB120 |
生产能力(吨/小时) | 40 | 60 | 80 | 100 | 120 |
干燥搅拌筒(mm) | Φ1200x5000 | Φ1500x6500 | Φ1500x6650 | Φ1500x7500 | Φ1800x8000 |
柴油消耗量(kg/t) | 6.5 | ||||
热沥青温度(°c) | 130-165(Adjustable) | ||||
废气排放量(毫克/标准立方米) | ≤100 | ||||
装机功率(千瓦) | 63.55 | 99.5 | 115 | 167 | 226 |
总重量(t) | 26 | 30 | 40 | 55 | 70 |
运输尺寸(长x宽x高)(米) | 17.1x3.09x4 | 20x3.09x4 | 23x3.09x4 | 23x3.09x4 | 23x3.09x4 |
站覆盖面积(长x宽x高)(米) | 17x37x5.5 |
-
