300T Self-propelled Barge

Overall length: 39.5m

Total width: 9.0m

Moulded depth: 2.0m

Load capacity: 300T

Design full load draft depth: 1500mm

Rated deck load: 6T/㎡

Design no-load draft depth: 800mm

Non-load speed: 20km/h

Full-load speed: 15km/h

Get A Price Now! Chat Online Product Video

Description Parameter Related Products Get In Touch

Description

Parameter

Item	Deck barge		Note
Main dimensions and parameters	Overall length	39.5m
	Total width	9.0m
	Moulded depth	2.0m
	Load capacity	300T
	Design full load draft depth	1500mm
	Rated deck load	6T/㎡
	Design no-load draft depth	800mm
	Non-load speed	20km/h
	Full-load speed	15km/h
Floating body materials	baseboard	12mm	Surface blasting and rust removal, spraying 4 layers of epoxy zinc-rich marine special paint.
	Side plate	6mm
	Bottom plate	8mm
	Length	35m
	Width	9.0m
	Height	2.0m
	Plate material	CCSA/B Marine board
Propeller(2 sets)	Diameter of impeller	800mm
	Engine	Manufacturer	Weichai Marine
		Model	WD615
		Power	145kwX2
		Rotation speed	900r/min
Control room	Length	3.0m	The upper and lower layers are designed to effectively save the usable area. Wall color is white, material is steel, door window is aluminium alloy sliding type
	Width	2.6m
	Height	1.9m
Crew lounge	Length	4.0m
	Width	3.0m
	Height	2.0m
Passage deck	Length	4.5m	Can be lifted up and down
Passage deck	Width	4.2m	Can be lifted up and down
Anchor	1 set
Total power: 290kw
Generator set: 20kw
Fuel consumption of equipment(full speed): about 22L/h
Total weight: about 130 ton
Production period: 50 working days
